Homeline by Stelrad Buying Guide


There’s no better way to complete any central heating system than with our large range of radiators. The Homeline range from Stelrad Radiator Group offers quality panel radiators in a large variety of sizes and types from a brand that's trusted by the trade.

The choice includes Single panel Type 11 radiators which have one panel and one convector fin. Double panel radiators come in two types: Type 21 radiators have a double panel and one convector fin, while Type 22 radiators have a double panel and two convector fins. There are also triple panel Type 33 radiators as well, which have three panels and three convector fins.

When deciding which radiator is the right one for you, check the size and BTU for each product. There’s a radiator that’s right for every room but it is essential the radiator is sized properly to ensure the level of comfort heating from each unit in the home. Radiators are the right choice for traditional boiler driven and modern renewable heat pump driven heating systems. In all heating system installations, the installation will benefit from adequate levels of insulation to stop heat escaping from the home.

Radiator types

Type 11 Compact_K1.jpg

Type 11 single radiators

  • Single panel and single convector fin
  • Best for small or narrow rooms, as heat output is less than Type 21 and 22 radiators
  • Slimline 57mm thickness
  • Available in heights 500, 600, 700 & 900mm
  • Available in widths 500, 600 & 700mm
Shop Type 11 radiators
Type 21 Compact_P+.jpg

Type 21 double plus radiators

  • Double Panel with single convector fin
  • Best for narrow spaces where higher heat output is required
  • 40% higher output on average compared to single panel radiators
  • 67mm thickness
  • Available in heights 500, 600 & 700mm
  • Available in widths 400 - 1600mm
Shop Type 21 radiators
Type 22 Compact_K2.jpg

Type 22 double premium radiators

  • Double panel with double convector fin
  • Best for large rooms where higher heat outputs are required
  • 25% higher output on average compared to double plus radiators
  • 80% higher output on average compared to single panel radiators
  • 100mm thickness
  • Available in heights 500, 600 & 700mm
  • Available in widths 400mm
Shop Type 22 radiators
Type 33 Compact_K3.jpg

Type 33 triple premium radiators

  • Three panels with three convector fins
  • Best for large rooms where higher heat outputs are required
  • Ideal for low temperature heating systems, providing outstanding heat outputs from a smaller radiator footprint
  • Available in heights 400mm - 900mm
  • Available in widths 600mm - 2000mm
Shop Type 33 radiators
